1 Programme selector
2 “Start/Pause“ button
3 “Reset/Drain“ button
4 “Temperature“ button
5 “Start delay“ button
6 Child lock combination
7 “Spin“ button
8 Time
9 Temperature
10 Washing phase
INDICATORS
Detergent over dosage
Door open
Failure: Service
Failure: Clean pump
Failure: Water tap closed
In the event of any failure, refer to the
“TROUBLESHOOTING“ section
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
CONTROL PANEL
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Lid handle
2. Lid
3. Control panel
4. Detergent dispenser
5. Drum
6. Water lter - behind the cover
7. Mobility lever (depending on model)
8. Adjustable feet (x2)
5.
1.
6.
7.
2.
3.
4.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover or
water softener.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch. Bleach.
Pour in softener, starch or bleach solution only
up to the “max” mark.
Release button
Press to remove tray for cleaning.
EN
Quick guide
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bracket is removed.
For more detailed instructions on how to remove it, see the Installation Guide.
1 2 3 4 5 6
7
10 89
Max load 6,0 Kg
Power consumption in o-mode 0,11 W / in left-on mode 0,11 W
Detergents and additives
Recommended
detergent
Residual
dampness % *
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Programme
Temperatures
Max.
Spin speed
(rpm)
Max
load
(kg)
Dura-
tion (h :
m)
Prewash
Main
wash
Softener
Powder Liquid
Setting Range
Rapid 30’ 30°C 20 - 30°C 1200 3,0 0:30
–
62 0,250 42 26
40°C 40°C
1151 6,0 3:15 –
53 0,657 52 39
1151 3,0 2:35 –
53 0,272 40 26
1151 1,5 2:20 –
53 0,163 30 23
Aqua saver 40°C 20 - 40°C 1200 2,5 ** –
– –
– – – –
Colours 40°C 20 - 60°C 1000 4,0 **
– – – –
Jeans 40°C 20 - 60°C 1000 4,0 **
–
– – – –
Hygiene 60°C 60°C 1200 6,0 ** –
– – – –
20°C 20°C 1200 6,0 1:50 –
–
53 0,150 48 20
Rinse & Spin – – 1200 6,0 ** – –
– – – – – –
Spin – – 1200 6,0 ** – – – – – – – – –
Wool 40°C 20 - 40°C 1000 1,0 ** –
–
– – – –
Delicates 40°C 20 - 40°C 1000 1,5 **
–
– – – –
Synthetics 40°C 20 - 60°C 1200 3,0 2:15
47 0,630 40 40
Cotton 60°C 20 - 95°C 1200 6,0 2:30
57 1,040 48 55
Mixed 40°C 20 - 60°C 1200 3,0 ** –
– – – –
Dosing required Dosing optional
* After programme end and spinning with maximum selectable spin speed, in default
programme setting.
** The duration of the programme is shown on the display.
6th Sense - The sensor technology adapts water, energy and programme duration to your
wash load.
Eco 40-60 - Test wash cycle in compliance with 2019/2014 regulation. The most ecient
programme in terms of energy and water consumption for washing normally soiled cotton
laundry. Display only: Spin speed values shown on the display can slightly diers from the
values stated in the table
For all Test Institutes
Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.
Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options. The values given for programmes other than the eco 40-
60 programme are indicative only.
