2
Quick Guide
EN
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab) - If you use powder or liquid detergent, this option
should be o.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
Please scan the QR code on your product in order to have more detailed information.
PUSH&GO - button is an easily distinguishable button that allows you
direct access to the Push&GO program, a wash and dry cycle that
ensures great cleaning performance in a short time. You don’t have to worry
which program to choose, Push&GO cycle will do the work for you.
EXTRA - makes it possible to carry out a heavy-duty wash cycle of
large crockery up to a max height of 53cm. baking pans, oven grids,
dripping pans, hob grids, large saucepans, serving dishes, pizza dishes,
stainless-steel hood lters. Remove the upper rack to load bulky crockery.
Release the two locks (right and left) and pull out the rack.
When the upper rack is tted, the locks must be always
closed.
In order for the water to reach the crockery everywhere,
arrange it as shown in the Figure.
Do not start the dishwasher without the upper rack
using wash cycles other than EXTRA.
To carry out the wash cycle Extra pour the detergent
DIRECTLY INTO THE TUB and not into the dispenser.
HALF LOAD using the upper or lower rack - If there are not many
dishes to be washed, a half load cycle may be used in order to save
water, electricity and detergent. Remember to load the upper or lower
rack only, and to reduce the amount of detergent accordingly.
More information in the Daily Reference Guide on website.
CLEANING AND MAINTENANCE
LOADING THE RACKS
CAPACITY: 10 standard place-settings
UPPER RACK
Load delicate and light dishes: glas-
ses, cups, saucers, low salad bowls.
(loading example for the upper rack)
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates
and lids should ideally be placed at the sides to avoid in-
terferences with the spray arm.
(loading example for the lower rack)
CUTLERY BASKET
The basket is equipped with top grilles for improved cut-
lery arrangement. The cutlery basket should be posi-
tioned only at the front of the lower rack.
Knives and other utensils with sharp edges must be
placed in the cutlery basket with the points facing
downwards or they must be positioned horizontally
in the tip-up compartments on the upper rack.
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray
arm, turn the plastic locking
ring in a clockwise direction.
The lower spray arm may
be removed by pulling
it upwards.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address:
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
Auto Door is a convection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying
performance every day. Door opens at the temperature that is safe to
your kitchen furniture.
