Прирачник
2
Quick Guide
EN
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab) - If you use powder or liquid detergent, this option
should be o.
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
PUSH&GO - button is an easily distinguishable button that allows you
direct access to the Push&GO program, a wash and dry cycle that
ensures great cleaning performance in a short time. You don’t have to worry
which program to choose, Push&GO cycle will do the work for you.
EXTRA - makes it possible to carry out a heavy-duty wash cycle of
large crockery up to a max height of 53cm. baking pans, oven grids,
dripping pans, hob grids, large saucepans, serving dishes, pizza
dishes, stainless-steel hood lters.
Remove the upper rack to load bulky crockery.
Release the two locks (right and left) and pull out the rack.
When the upper rack is tted, the locks must be always
closed.
In order for the water to reach the crockery everywhere,
arrange it as shown in the Figure.
Do not start the dishwasher without the upper rack
using wash cycles other than EXTRA.
To carry out the wash cycle Extra pour the detergent
DIRECTLY INTO THE TUB and not into the dispenser.
HALF LOAD using the upper or lower rack - If there are not many
dishes to be washed, a half load cycle may be used in order to save
water, electricity and detergent. Remember to load the upper or lower
rack only, and to reduce the amount of detergent accordingly.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address:
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
Auto Door is a convection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying
performance every day. Door opens at the temperature that is safe
to your kitchen furniture.
OPTIONS AND FUNCTIONS
Please scan the QR code on your product in order to have more detailed information.
LOADING THE RACKS
CAPACITY: 10 standard place-settings
UPPER RACK
Load delicate and
light dishes: glas-
ses, cups, saucers,
low salad bowls.
(loading example
for the upper
rack)
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
LOWER RACK
(loading example
for the lower rack)
For pots, lids, plates, salad
bowls, cutlery etc. Large plates
and lids should ideally be pla-
ced at the sides to avoid inter-
ferences with the spray arm.
The lower rack has tip-up sup-
ports which can be used in a
vertical position when arran-
ging plates or in a horizontal
position (lower) to load pans
and salad bowls easily
CUTLERY BASKET
The basket is equipped with
top grilles for improved cut-
lery arrangement. The cut-
lery basket should be posi-
tioned only at the front of
the lower rack.
Knives and other utensils
with sharp edges must
be placed in the cutlery basket with the
points facing downwards or they must be
positioned horizontally in the tip-up com-
partments on the upper rack.
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
1 2 3
4
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in
aclockwise direction.
The lower spray arm may be
removed by pulling it upwards.
CARE AND MAINTENANCE
More information in the Daily Reference Guide on website.
Преземете прирачник на англиски јазик (PDF, 38.85 MB)
