Прирачник Indesit BTW S50400 EU/N Машина за перење алишта

Прирачник

1 Programme selector

2 “Start/Pause” button

3 “Reset/Drain” button

4 Programme sequence indication

5 “Start delay” button

6 “Spin speed” button

7 Time indication

INDICATORS

Door locked

Failure: Service

Failure: Clean lter

Failure: Water tap closed

In the event of any failure, refer to the

“TROUBLESHOOTING” section

CONTROL PANEL

PROGRAMME CHART

PRODUCT DESCRIPTION

1. Lid handle

2. Lid

3. Control panel

4. Detergent dispenser

5. Drum

6. Water lter - behind the cover

7. Mobility lever (depending on model)

8. Adjustable feet (x2)

5.

1.

6.

7.

2.

3.

4.

8.

DETERGENT DISPENSER

Main wash compartment

Detergent for the main wash, stain remover or

water softener.

Prewash compartment

Detergent for the prewash.

Softener compartment

Fabric softener. Liquid starch. Bleach.

Pour in softener, starch or bleach solution

only up to the “max” mark.

Release button



Press to remove tray for cleaning.



* After programme end and spinning with maximum selectable spin speed, in default

programme setting.

** The duration of the programme is shown on the display.

The sensor technology adapts water, energy and programme duration to your wash load.

Eco 40-60 - Test wash cycle in compliance with 2019/2014 regulation. The most ecient

programme in terms of energy and water consumption for washing normally soiled cotton

laundry. Display only: Spin speed values shown on the display can slightly diers from the

values stated in the table.

For all Test Institutes

Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.

Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

the programmes, without options. The values given for programmes other than the eco 40-60

programme are indicative only.

EN

Quick guide

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bracket is removed.

For more detailed instructions on how to remove it, see the Installation Guide.

5

2

3

1

4

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

6

7

Max load 5,0 Kg

Power consumption in o-mode 0,11 W / in left-on mode 0,11 W

Detergents and additives

Recommended

detergent

Residual

dampness % *

Energy

consumption kWh

Total water lt

Loundry

temperature °C

Programme

Temperatures

Max, spin

speed (rpm)

Max

load

(kg)

Dura-

tion

(h : m)

Pre-

wash

Main

wash

Softener

Pow-

der

Liquid

Setting Range

Turn & Go

30°C 30°C 1000 3,5 ** –

 

–



– – – –

Sintetici

40°C 40°C 1000 3,0 2:15

    

47 0,630 40 40

Cotone

60°C 40°C-90°C 1000 5,0 2:40

    

64 0,950 46 55

Eco 40-60

Eco 40-60

40°C 40°C

951 5,0 3:05 –

   

60 0,611 45 34

951 2,5 2:30 –

   

62 0,411 36 31

951 1,5 2:30 –

   

66 0,455 36 32

20 °C

20°C

20°C 20°C 1000 5,0 3:05 –

 

–



62 0,250 46 20

Wool 20°

20°

20°C 20°C 1000 1,0 ** –

 

–



– – – –

Delicates 30°

30°

30°C 30°C 1000 1,5 ** –

 

–



– – – –

Mix 45’ 40°

40°

40°C 20°C-40°C 1000 5,0 ** –

   

– – – –

Cotton 30°

30°

30°C 30°C 1000 3,0 0:30 –

 

–



66 0,250 42 26

Synthetics 30°

30°

30°C 30°C 1000 3,0 ** –

 

–



– – – –

Spin + Drain

– – 1000 5,0 – – – – – – – – – –

Rinse + Spin

– – 1000 5,0 – – –



– – – – – –

 Dosing required  Dosing optional
