Replace the Remote Control Battery
1 Press and slide the back cover to open the battery
compartment of the remote control.
2 Insert two AAA size batteries (included). Make sure the
(+) and (–) ends of the batteries match the (+) and (–)
ends indicated in the battery compartment.
3 Close the battery compartment cover.
Precautions Concerning Batteries
• Be sure to insert the batteries with correct positive “ (+)
” and negative “(–)”
polarities.
• Use batteries of the same type. Never use different types of batteries
together.
• Either rechargeable or non-rechargeable batteries can be used. Refer to the
precautions on their labels.
• Be aware of your fingernails when removing the battery cover and the
battery.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of
excessive heat.
• Remove the battery from the remote control when not in use for a long
period of time, as corrosion or battery leakage may occur and result in
physical injury, and/or property damage, and/or fire.
9 /
Play/pause/resume playback in BT/USB mode. Press and hold to activate
the pairing function in Bluetooth mode or disconnect the existing paired
Bluetooth device.
10 NIGHT
Switch to NIGHT EQ effect.
11 MOVIE
Switch to MOVIE EQ effect.
12 BASS+/-
Increase/decrease the bass level.
Preparations
Prepare the Remote Control
The provided Remote Control allows the unit to be operated from a distance.
•
Even if the Remote Control is operated within the effective range 19.7
feet (6m), remote control operation may be impossible if there are any
obstacles between the unit and the remote control.
•
If the Remote Control is operated near other products which generate
infrared rays, or if other remote control devices using infra-red rays are used
near the unit, it may operate incorrectly. Conversely, the other products
may operate incorrectly.
6
Placement and Mounting
Placement
A If your TV is placed on a table, you can
place the unit on the table directly in
front of the TV stand, centered with the
TV screen.
B If your TV is attached to a wall, you can mount the unit on the wall directly
below the TV screen.
Wall Mounting (if using option-B)
Note:
- Installation must be carried out by qualified personnel only. Incorrect
assembly can result in severe personal injury and property damage (if you
intend to install this product yourself, you must check for installations such
as electrical wiring and plumbing that may be buried inside the wall). It is
the installer’s responsibility to verify that the wall will safely support the
total load of the unit and wall brackets.
- Additional tools (not included) are required for the installation.
- Do not overtighten screws.
• Do not use any batteries other than those specified.
• Do not mix new batteries with old ones.
• Never recharge a battery unless it is confirmed to be a rechargeable type.
- Keep this instruction manual for future reference.
- Use an electronic stud finder to check the wall type before drilling and
mounting.
686 mm / 27 inches
3 mm / 0.12 inches
> 30 mm / 1.2 inches
D < 8 mm / 0.3 inches
2 × 6 mm / 0.24 inches
HOLE IN WALL
