English | 13
Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture. There is a risk of explosion and
short-circuiting.
Symbols
The following symbols may be important for the operation of
your power tool. Please take note of these symbols and their
meaning. Correctly interpreting the symbols will help you to
operate the power tool more effectively and safely.
Symbols and their meaning
Tool data logging is enabled in this tool.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The machine is intended for driving in and loosening screws
and bolts as well as for tightening and loosening nuts within
the respective range of dimension.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Tool holder
(2)
Carrying strap
a)
(3)
Belt clip
a)
(4)
Battery
a)
(5)
Battery release button
a)
(6)
"Automatic shutdown (ABR)" button
(7)
"Automatic shutdown (ABR)" LED
(8)
Rotational direction switch
(9)
On/off switch
(10)
"PowerLight" lamp
(11)
Handle (insulated gripping surface)
(12)
Application tool (e.g. impact socket)
a)
a)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Cordless Impact Wrench GDS 18V-400
Article number
3601JK00..
Rated voltage V= 18
No-load speed
A)
min
-1
0–2500
Impact rate
A)
min
-1
0–3700
Max. torque
A)
Nm 400
Machine screw diameter mm M10–M20
Tool holder ½"
Weight according to
EPTA-Procedure 01:2014
B)
kg 1.8–2.6
Recommended ambient tem-
perature during charging
°C 0 to +35
Permitted ambient temperat-
ure during operation and dur-
ing storage
°C –20 to +50
Recommended rechargeable
batteries
GBA 18V...
ProCORE18V...
Recommended chargers GAL 18...
GAX 18...
GAL 36...
A) Measured at 20−25°C with rechargeable
batteryGBA18V5.0AhM-C.
B) Depends on battery in use
Noise/vibration information
Noise emission values determined according to
EN62841-2-2.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 91.5dB(A); sound power level
102.5dB(A). Uncertainty K=3dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according toEN62841-2-2:
Tightening screws and nuts of the maximum permitted size:
a
h
=10 m/s
2
, K=1.5 m/s
2
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Bosch Power Tools 1 609 92A 5MF | (27.11.2020)
